Falcon Vehicle System with NVIDIA® Jetson Orin™ NX
More Information
The Falcon Vehicle System, powered by Jetson Orin™ NX, is a compact, rugged, IP67-rated Edge AI compute system designed specifically for tough vehicle applications. Falcon sets a new standard for autonomous heavy equipment by combining vehicle-native T1 Ethernet with powerful Edge AI. Bring advanced AI capabilities to the Edge with a system engineered to perform right where the action happens.
Built to withstand harsh conditions with IP67 protection and rugged design for nonstop AI performance on the move.
Specifications
| NVIDIA® GPU SoC Module Compatibility | Pre-integrated with Jetson Orin™ NX (Super Mode Enabled) |
|---|---|
| Networking | • 2x 100BASE-T1 or 1000BASE-T1(with some SI limitations TBD) |
| Camera Inputs | 4x FAKRA GMSL2 Inputs |
| USB | • 1x USB2.0 DRP (Type-C) |
| Storage | 1x M.2 Key-M (NVMe) slot (4-lane PCIe Gen 3/4) |
| CAN Bus | 2x CAN 2.0B / FD |
| Input Power | +9V to +36V (+14V Nominal) |
| Dimensions | 152mm x 115mm x 52mm (5.98” x 4.53” x 2.05”) |
| Operating Temperature | • -25°C to +70°C (-13°F to +158°F) |
| Max Weight | 1.15kg (2.54 lbs) |
Downloads
Falcon Vehicle System
| Package Info | Board Support Package | Release Notes | Date Last Updated |
|---|---|---|---|
| JetPack 6.2.2 – L4T r36.5.0 | Orin NX / Nano Laird L4T r36.5.0 BSP | Orin NX / Nano L4T r36.5.0 Release Notes | 06-May-26 |
Ordering Information
| Main Products | |
|---|---|
| Part Number | Description |
| ESG615-0Y | Falcon Vehicle System with NVIDIA Jetson Orin™ NX 16GB Module, WiFi6/BT Module, 1TB NVMe, Global 5G |
| Cables/Accessories | |
|---|---|
| Part Number | Description |
| CBG858 | Falcon I/O Development Cable |
| MSG124 | Falcon I/O Development Cable (CBG858) + Power Supply |
Custom Design
Looking for a customized NVIDIA® Jetson Orin™ Product? Click below to tell us what you need.
